参数：
材质：不锈钢 304 (1/2"~6"), 黄铜 (1/2"~2"), 铁 (2-1/2"~6")
尺寸：1/2"~6"
耐压强度：Max. 6000 psi (1/2", 3/4"), Max. 1200 psi (1"~2")
螺纹型式：NPT、M
RoHS：符合
认证：cULus (E490826)
规格表：
M螺纹
| 公称尺寸 | M螺纹 | 产品型号 | 每箱数量 (Pcs) | 每箱重量 (Kg) |
|---|---|---|---|---|
| 1/2 | M20X1.5 | KF-XG1F11 | 10 | 2.9 |
| 3/4 | M25X1.5 | KF-XG2F11 | 10 | 3.8 |
| 1 | M32X1.5 | KF-XG3F11 | 10 | 5.3 |
| 1-1/4 | M40X1.5 | KF-XG4F11 | 5 | 3.5 |
| 1-1/2 | M50X1.5 | KF-XG5F11 | 5 | 4.1 |
| 2 | M63X1.5 | KF-XG6F11 | 5 | 5.8 |
| 2-1/2 | M75X1.5 | KF-XG7F11 | 2 | - |
| 3 | M90X1.5 | KF-XG8F11 | 2 | - |
| 4 | M110X1.5 | KF-XG9F11 | 2 | - |
| 5 | M140X1.5 | KF-XG10F11 | 1 | - |
| 6 | M164X1.5 | KF-XG11F11 | 1 | - |
| 公称尺寸 | NPT螺纹 | 产品型号 | 每箱数量 (Pcs) | 每箱重量 (Kg) |
|---|---|---|---|---|
| 1/2 | 1/2" | KF-XG1F21 | 10 | 2.9 |
| 3/4 | 3/4" | KF-XG2F21 | 10 | 3.8 |
| 1 | 1" | KF-XG3F21 | 10 | 5.3 |
| 1-1/4 | 1-1/4" | KF-XG4F21 | 5 | 3.5 |
| 1-1/2 | 1-1/2" | KF-XG5F21 | 5 | 4.1 |
| 2 | 2" | KF-XG6F21 | 5 | 5.8 |
| 2-1/2 | 2-1/2" | KF-XG7F21 | 2 | - |
| 3 | 3" | KF-XG8F21 | 2 | - |
| 4 | 4" | KF-XG9F21 | 2 | - |
| 5 | 5" | KF-XG10F21 | 1 | - |
| 6 | 6" | KF-XG11F21 | 1 | - |
